X-Ray Baggage Scanning: Airport Security's Essential Tool

Airport baggage scanners are an essential component of airport security systems. They use X-ray technology to generate images of the contents within luggage, allowing security personnel to identify potential threats. These scanners can detect metallic and non-metallic objects, as well as organic materials such as food, liquids, drugs, and explosives. The use of X-rays ensures that security personnel can effectively see through luggage without the need for manual searches, enhancing efficiency, accuracy, and safety in the screening process.

X-ray scanners can detect metallic and non-metallic objects

X-ray scanners are used at airports to detect objects inside a person's body or luggage without physically removing clothes or making physical contact. They can detect both metallic and non-metallic objects, including those hidden in shoes and body cavities. This is particularly important given that non-metallic objects, such as plastic, have been used in airliner bombing attempts.

X-ray scanners work by sending out X-rays, which are electromagnetic waves with high energy that can penetrate many materials. The X-rays pass through the object being scanned and are then picked up by a detector. Different materials absorb X-rays at different levels, so the image on the monitor will show distinct items inside the bag. Objects are typically coloured on the display monitor based on the range of energy that passes through them, with inorganic and metal objects usually appearing in shades of orange.

X-ray scanners can detect the mass and density of objects inside a bag, but they cannot always establish what the objects are. This means that if luggage contains objects that arouse suspicion, security staff will need to manually search the bag.

X-ray scanners can also be used as full-body scanners to detect objects on or inside a person's body. These scanners can detect swallowed items or items hidden in body cavities. They are particularly useful in detecting drugs carried by couriers in their stomachs. However, there has been some controversy over the use of full-body scanners, with critics arguing that they are equivalent to strip searches and may violate basic human rights.

They can identify organic materials like food, drugs, and explosives

X-ray baggage scanners are essential tools in modern airport security systems. They produce colour-coded images of the contents of luggage, helping security personnel to identify potential threats. One of the key functions of these scanners is their ability to identify organic materials, such as food, drugs, and explosives.

Organic substances are materials that contain carbon and are typically derived from living organisms. They include a wide range of everyday items, such as food, clothing, paper products, and plastics. On an X-ray baggage scanner, organic substances are coded with the colour orange. This is because most explosives are organic, and using this colour helps security personnel quickly identify potentially harmless items like food or clothing, as well as more suspicious objects.

The reason organic materials appear orange on a scanner is due to the way the scanners are designed to differentiate between materials. X-ray scanners use different energy levels to analyse the contents of luggage. When X-rays pass through organic materials, they interact with carbon atoms in a specific way, causing the scanner's software to code these items in shades of orange.

The colour-coding system provides clarity and is crucial for efficient and accurate luggage inspection. It allows security personnel to identify potential threats and ensure that prohibited items do not make it past security checkpoints. Misinterpretation of scanner images can have serious consequences, potentially compromising safety. Therefore, accurate interpretation of these colours is vital for maintaining airport security.

In addition to visual inspection by security personnel, some airports also employ chemical sniffers to detect explosives and narcotics. These devices can analyse residue on electronic devices or other surfaces for traces of chemicals used to make bombs. This further enhances the ability of airport security to identify potential threats.

The scanners use colour-coding to identify different types of materials

Airport security uses X-ray scanners to inspect the contents of luggage. These scanners produce colour-coded images that security personnel can analyse to identify potential threats. The colour-coding system used by the scanners helps identify different types of materials.

Organic substances, such as food, paper, clothing, and explosives, typically appear in shades of orange on the scanner. This is because organic materials interact with X-rays in a specific way due to the presence of carbon atoms. This interaction causes the scanner software to colour-code these items in orange shades.

Inorganic substances, on the other hand, are represented by the colour blue. Inorganic substances do not contain carbon and are generally composed of minerals or metals. Examples include electronics, metal objects, glass items, and ceramics. The blue colour is a result of these materials' higher atomic numbers, which cause them to absorb X-rays more efficiently.

Mixed substances, consisting of both organic and inorganic components, show up as green on the scanner. Batteries, packaged goods, and composite tools are examples of items that fall into this category. The green hue is a result of the unique interaction between the X-rays and the composite nature of these items.

The brightness of the colours on the scanner is also significant. Thicker materials absorb more X-rays and appear darker, while thinner materials allow more X-rays to pass through and appear brighter. This helps security personnel differentiate between various items based on their thickness.

By understanding the colour-coding system and interpreting the colours accurately, security personnel can enhance their vigilance and ensure safer travel for everyone.

Carry-on baggage screening: electronics, food, and powders are separated for X-ray screening

X-ray screening is a standard security measure at airports. This technology is used to screen carry-on baggage for explosives and other dangerous items. The X-ray systems used in airports are typically dual-energy X-ray systems, which have a single X-ray source emitting X-rays in the range of 140 to 160 kilovolt peak (KVP). The KVP refers to the penetration of the X-ray, with higher KVP resulting in greater penetration.

When it comes to carry-on baggage screening, passengers are required to remove personal electronic devices larger than a cell phone, such as laptops, tablets, e-readers, and handheld game consoles, and place them in a separate bin for X-ray screening. This ensures that these items can be examined independently and reduces the risk of overlapping items in the X-ray image.

Food items are also subject to X-ray screening. While solid food can be transported in carry-on or checked baggage, travellers may be instructed by TSA officers to separate food items from their carry-on bags. This is to ensure that the food does not clutter the bag and obstruct clear images on the X-ray machine. Most food items, such as fruit, health bars, and sandwiches, can remain inside the carry-on bag during screening. However, special instructions apply to liquids, gels, aerosols, baby food, breast milk, and medically necessary items.

Powders are another category of items that may require separate screening. While powder-like substances over 12 oz/350 mL are recommended to be placed in checked baggage, powders in carry-on baggage will undergo secondary screening. Any powders that cannot be resolved by security officials will not be permitted in the cabin of the aircraft.

By separating electronics, food, and powders, TSA officers can effectively screen carry-on baggage and ensure the safety and security of all passengers.

Checked baggage screening: TSA screens approximately 1.3 million checked bags daily

The Transportation Security Administration (TSA) screens approximately 1.3 million checked bags daily for explosives and other dangerous items. The TSA is required by law to screen all checked luggage for explosives and other security threats that could be catastrophic on an aircraft.

Checked baggage screening begins at check-in, where bags are provided to TSA for security screening. The TSA uses a state-of-the-art, fully automated Checked Baggage Inspection System (CBIS) to screen checked luggage. The CBIS features a network of conveyor belts that sorts and tracks checked luggage, moving it through the security screening process and onto the area where the luggage is loaded onto the aircraft.

The CBIS utilizes two Explosive Detection System (EDS) units that generate a 3-D X-ray image of the contents of each checked bag. Each EDS unit can screen up to 700 bags per hour. The EDS analyzes the contents of the bag, completing a sophisticated and swift analysis of the 3-D image. It then determines whether the bag is cleared for travel or if it requires further screening.

If the EDS identifies a potential security threat, the image of the bag's contents is electronically sent for review by a TSA officer (TSO) located in a separate location. The TSO follows an established protocol, reviewing the image on-screen to determine if the bag is cleared to travel or if it needs to be sent for a physical inspection. If a TSO physically inspects a checked bag, the screening is done in clear view of a closed-circuit television camera. Travelers will receive a "Notice of Inspection" in their bag if it has been opened for physical inspection. Once the bag is cleared of any security threats and ready for travel, it is repacked and closed before being handed off to the airline.

The majority of checked baggage is screened without the need for a physical bag search. Nationwide, about 5% of checked bags require physical inspection by a TSO. The TSA also employs unpredictable security measures to accomplish its transportation security mission. These measures can change over time to meet evolving threats and achieve the highest levels of transportation security.
