Airport surveillance radar (ASR) systems are used to detect and display the presence and position of aircraft in the airspace around airports. ASRs are designed to provide short-range coverage in the general vicinity of an airport and to handle terminal area traffic through the observation of precise aircraft locations on a radarscope. The primary radar consists of a large rotating parabolic antenna dish that sweeps a vertical fan-shaped beam of microwaves around the airspace surrounding the airport. The secondary radar, often mounted on the primary antenna, interrogates the transponders of aircraft to transmit data on aircraft altitude, identification code, and emergency conditions.
| Characteristics | Values |
|---|---|
| Purpose | To detect and display the presence and position of aircraft in the terminal area, the airspace around airports. |
| Control system | The main air traffic control system for the airspace around airports. |
| Range | 40-60 nautical miles (75-110 km) |
| Altitude | Below 25,000 feet (7,620 metres) |
| Antenna type | Parabolic "dish" antenna |
| Antenna rotation | 12-15 revolutions per minute |
| Antenna gain | 34 dB |
| Beamwidth | 5° in elevation and 1.4° in azimuth |
| Frequency | 2.7-2.9 GHz (S band) or 2700-2900 MHz (E band) |
| Peak radiated power | 25 kW |
| Average power | 2.1 kW |
| Display | Radar screen, often located in the control tower or operations room |
| Backup | Diesel generator to continue operating during power outages |
Explore related products
What You'll Learn
Airport Surveillance Radar (ASR)
The systems at large airports consist of two different radar systems: the primary and secondary surveillance radar. The primary radar typically consists of a large rotating parabolic antenna dish that sweeps a vertical fan-shaped beam of microwaves around the airspace surrounding the airport. It detects the position and range of aircraft by microwaves reflected back to the antenna from the aircraft's surface. The dish rotates at a constant rate about a vertical axis so the beam scans the entire surrounding airspace about every 5 seconds. The antenna has a gain of 34 dB, a beamwidth of 5° in elevation and 1.4° in azimuth. It rotates at a rate of 12.5 RPM so the airspace is scanned every 4.8 seconds.
The secondary surveillance radar consists of a second rotating antenna, often mounted on the primary antenna, which interrogates the transponders of aircraft. Military, commercial, and some general aviation aircraft have transponders that automatically respond to a signal from the secondary radar by reporting an identification code and altitude. The secondary radar uses a second radar beacon antenna attached to the top of the primary radar antenna to transmit and receive aircraft data for barometric altitude, identification code, and emergency conditions.
The current generation of radar is the ASR-9, which was developed by Westinghouse Electric Corporation and first installed in 1989, with installation completing in 1995. The ASR-9 was the first airport surveillance radar to detect weather and aircraft with the same beam and be able to display them on the same screen. It has a digital Moving Target Detection (MTD) processor that uses doppler radar and a clutter map to provide advanced ability to eliminate ground and weather clutter and track targets. It is theoretically capable of tracking a maximum of 700 aircraft simultaneously.
The positions of the aircraft are displayed on a screen; at large airports, on multiple screens in an operations room at the airport called the Terminal Radar Approach Control (TRACON), monitored by air traffic controllers who direct the traffic by communicating with aircraft pilots by radio. They are responsible for maintaining a safe and orderly flow of traffic and adequate aircraft separation to prevent mid-air collisions.
