The AirPort Express is a now-discontinued Wi-Fi base station product from Apple. It was first introduced in 2004 and was Apple's entry into the ultra-portable router market. The AirPort Express can be used to extend Wi-Fi from a wireless router and act as an access point, allowing wireless network printing and streaming music from compatible devices.
| Characteristics | Values |
|---|---|
| First Version Release Date | July 7, 2004 |
| First Version Model | M9470LL/A, model A1084 |
| First Version Features | Analog-optical audio mini-jack output, a USB port for remote printing, and one Ethernet port |
| Second Version Release Date | March 2008 |
| Second Version Model | MB321LL/A, model A1264 |
| Second Version Features | 802.11a/n (5 GHz) mode, 2.4 GHz and 5 GHz bands |
| Purpose | To set up or extend a wireless network |
| Number of Connectable Wireless Devices | Up to 10 |
| Audio Output | Yes |
| iTunes Capabilities | Yes |
| AirPlay | Yes |
| AirPlay 2 | Yes |
| Apple Home App Integration | Yes |
| Discontinuation Date | April 2018 |
Explore related products
What You'll Learn
Wireless network extension
The AirPort Express is a discontinued Wi-Fi base station product from Apple. It can be used to extend a wireless network anywhere. For instance, it can be used in hotels that only have wired internet in the rooms to create a wireless network. It can also be used to extend the Wi-Fi of another non-Apple Access Point.
To use the AirPort Express as a Wi-Fi extender, you need to connect it to a modem or router with an Ethernet cable. The setup will work best if the network name, security settings, and password are the same on both the primary and secondary devices. The AirPort Express can be set up as a secondary router in Bridge Mode, which will allow it to pass traffic to the primary router.
On a Mac, open the AirPort Utility program by navigating to "Go," then "Applications," and choosing the "Utilities" folder. On a Windows PC, the program can be found in the "Start Menu" under "Programs" and then "AirPort." Connect to the primary router using a wired Ethernet cable. In the AirPort Utility, set "Connection Sharing" to "Share a Public IP Address."
Next, disconnect from the primary router and connect to the AirPort Express (secondary router) using another Ethernet cable. In the AirPort Utility, set "Connection Sharing" to "Off (Bridge Mode)." Click "Update" and then connect to the secondary router using the "Base Station Chooser" in the setup program. Click "Manual Setup," then "Airport," and then "Wireless." Choose "Extend a Wireless Network" in the "Wireless Mode" menu, select the network name, and enter the password. Click "Update" again.
Now, your existing Wi-Fi network has been extended using the AirPort Express as an additional base station. You can adjust the placement of the devices to maximize network strength as needed.
Airports and English Signage: A Universal Standard?
You may want to see also
Explore related products
Wired to wireless connection
The Apple AirPort Express is a small device that can be used to set up or extend a wireless network anywhere. It is a discontinued Wi-Fi base station product from Apple Inc. that was first introduced in 2004. The AirPort Express can be used to create a wireless access point by connecting it to an Ethernet network or a modem. It can also be used to stream music wirelessly from a computer or iOS/OS X device to a stereo system or powered speakers.
To set up the AirPort Express as a wireless access point, you need to connect the Ethernet cable from your DSL or cable modem to the AirPort Express. The AirPort Express can then be plugged into an electrical socket, and it will automatically turn on. Once the status light turns green, it is ready to use and can provide wireless Internet access for up to 10 users.
The AirPort Express can also be used to stream music wirelessly. It has a 3.5mm mini-jack port that can be connected to powered speakers or a stereo system. To stream music from a computer, you can use iTunes, and for iOS/OS X devices, you can use AirPlay. The AirPort Express can also be used with AirFoil and TuneBlade software to stream system-wide audio.
The AirPort Express has a USB port that can be used to connect a printer, allowing wireless network printing for all connected users. It is compatible with both Mac and Windows operating systems and supports various Wi-Fi flavours, including 802.11b, 802.11a, 802.11g, and 802.11n. While Apple discontinued the AirPort Express in 2018, it continues to support later models, and the device remains a versatile option for wired-to-wireless connections and streaming audio.
Ronald Reagan Airport: Easy Metro Access?
You may want to see also
Explore related products
Audio streaming
The AirPort Express is a Wi-Fi base station product from Apple Inc. that offers audio output capability. It was the first AirPlay device to receive streamed audio from a computer running iTunes on the local network. The audio output feature of the AirPort Express can be used to wirelessly stream audio files from within iTunes to an attached stereo system.
To stream music from your computer, open iTunes. You will notice a drop-down menu that lists the available AirPlay devices in your setup. Choose AirPort Express from the list, and the music you play in iTunes will play over the home theatre receiver or powered speakers that are connected to your AirPort Express. On an iPhone, iPad, or iPod, look for the arrow-in-a-box Airplay icon when playing music or audio. Tap on the Airplay icon to bring up a list of Airplay sources. Choose the AirPort Express, and you can stream music from compatible Airplay-enabled apps from your iPad, iPhone, or iPod, and listen to the music through the speakers or stereo connected to your AirPort Express.
The AirPort Express has a 3.5mm mini-jack port that can connect to powered speakers or, via an RCA connection adapter, to a soundbar, sound base, stereo/home theatre receiver, or audio system that has a set of analog stereo audio input connections. The AirPort Express has a light on the front that shines green when it is connected to your home network and ready to stream. It shines yellow if it is not connected to your home network.
The AirPort Express can be used to extend Wi-Fi from your wireless router and it can also act as an access point. It works with all popular flavours of Wi-Fi, including 802.11b, 802.11a, 802.11g, and 802.11n. It is also compatible with both Mac and Windows operating systems.
Seattle Airport: A Gym Haven for Travelers
You may want to see also
Explore related products
![Computer Networking Bible: [3 in 1] The Complete Crash Course to Effectively Design, Implement and Manage Networks. Including Sections on Security, Performance and Scalability](https://m.media-amazon.com/images/I/61dLfowXo3L._AC_UY218_.jpg)
Compatibility with devices
The AirPort Express is compatible with both Mac and Windows operating systems. It can be used with all popular flavours of Wi-Fi, including 802.11b, 802.11a, 802.11g, and 802.11n.
The AirPort Express can be used to add wireless connectivity to any device with an Ethernet port but no wireless card, such as a gaming console. It can also be used to stream music to speakers, either wirelessly or by using the 3.5 mm mini-jack socket. This can be done by plugging the mini-jack into speakers and then streaming music in digital or analog from the iTunes library on a desktop or laptop computer.
The AirPort Express can also be used to stream music from an iPhone or iPod Touch. It is compatible with AirPlay and AirPlay 2, allowing users to stream audio from a computer running iTunes on the local network.
The device has a USB port that can be used to charge the first-generation iPod Shuffle, although this use is not supported by Apple.
The AirPort Express can be used to create a wireless network or extend an existing one. It can be connected to a DSL or cable modem, or an Ethernet network, to provide wireless internet access for up to 10 users. The latest model allows up to 50 networked users.
Lockers at European Airports: Where to Store Your Luggage
You may want to see also
Explore related products
Router functionality
The AirPort Express is a Wi-Fi base station product from Apple Inc. It is a small device that can be used to set up an Internet access point. It works with all popular flavours of Wi-Fi, including 802.11b, 802.11a, 802.11g, and 802.11n. It is also compatible with both Mac and Windows operating systems.
The AirPort Express can be used to extend Wi-Fi from your wireless router and act as an access point. It can be connected to a modem or an Ethernet-based network. Up to 10 wireless devices can connect to the AirPort Express, and it can share that wireless connection with all of them, allowing them to connect to the home network.
The AirPort Express can also be used to stream music. It can access music or audio streamed from an iPhone, iPad, iPod, or iTunes via your computer. Using AirPlay, the music can be played on a connected powered speaker, stereo, or home theatre system. The AirPort Express has a 3.5 mm mini-jack port that can connect to powered speakers or, via an RCA connection adapter, to a soundbar, sound base, stereo/home theatre receiver, or audio system with analog stereo audio input connections.
The AirPort Express also has a USB port that can be used to connect a non-network printer, allowing wireless network printing on any printer.
Airports and July 4th: What's the Rush?
You may want to see also
Frequently asked questions
The AirPort Express is a discontinued Wi-Fi base station product from Apple Inc. It was first introduced in 2004 and was Apple's entry into the ultra-portable router market.
The AirPort Express can be used to set up or extend a wireless network. It can also be used to stream music from iTunes or Airplay to a set of speakers or a stereo system. Additionally, it has a USB port that can be used for remote printing.
The AirPort Express can provide wireless internet access for up to 10 users or devices.
The AirPort Express is compatible with iPhones, iPads, iPods, Macs, and Windows PCs. It also works with popular Wi-Fi flavours, including 802.11b, 802.11a, 802.11g, and 802.11n.
To set up the AirPort Express as an Internet access point, connect the Ethernet cable from your DSL or cable modem to the AirPort, and then plug the AirPort into an electrical socket.
