Roberta Aguirre
The Apple AirPort Extreme Base Station A1301 (MB763LL/A) router can be reset in several ways, depending on the issue you are facing. A soft reset can be performed if you have forgotten your password, while a hard reset can be done if your AirPort has stopped responding or has serious accessibility issues. A factory reset is also an option, which will restore your AirPort to its default settings.
Explore related products
What You'll Learn
Soft reset instructions
Soft resetting your AirPort Extreme A1301 can be done in two ways, depending on the base station model.
Soft Reset Method 1:
- Ensure that the AirPort Extreme is connected to a power source.
- Disconnect any Ethernet cables from the base station.
- On your Apple device, click on the Apple menu (top left corner).
- Select 'System Preferences'.
- Click on the 'Network' icon.
- Choose 'AirPort' from the list of connections on the left.
- Click the 'Advanced' button.
- Click to select the 'TCP/IP' tab.
- Set the 'Configure IPv4' to 'Using DHCP'.
Soft Reset Method 2:
- Ensure that the AirPort Extreme is connected to a power source.
- Press and hold the reset button for 1 second. The reset button is located next to the ports.
- Release the button.
- The middle LED light will blink once every second, indicating that the device is in soft reset mode.
- The base station password will be set to "public", and the IP address will be reset.
- From the Wi-Fi status menu, choose the network created by the base station.
- Open the AirPort Admin Utility for Graphite and Snow 4.2.5 to reconfigure the base station.
Note: Unless you have been given an IP address by your ISP or system administrator, do not change the IP address.
Navigating the Airport in Need for Speed: Underground 2
You may want to see also
Explore related products
Hard reset instructions
The AirPort Extreme A1301 model was produced between March 2009 and October 2009. If your router is not working as expected, dropping connections, or not being responsive, you should reset it to see if the problems persist. You might also want to reset your router if you've forgotten the password or misconfigured it and can no longer access it.
There are two types of reset you can perform on your Apple Extreme Base Station. If you have forgotten your base station password, perform a Soft Reset. If your AirPort has stopped responding or has serious accessibility issues, perform a Hard Reset to revert it to its default factory configuration.
- Unplug the power cable from the back of the AirPort Extreme.
- Locate the reset button. The reset button is a tiny button, typically the second from the right, next to the ports or the power port.
- Insert a pin, pen, or paper clip into the reset button and press it down.
- While holding the reset button, reconnect the power plug to the AirPort Extreme.
- Keep the reset button depressed for about 5 to 8 seconds or until you see the light on the front of the AirPort Extreme flashing rapidly. The colour should be an amber or yellow colour.
- Release the button, and the AirPort Extreme will reset.
- Wait about a minute for the AirPort Extreme to restart.
- You can now use AirPort Utility to reconfigure the AirPort Extreme.
Note: Holding the reset button for 5 seconds or longer will do a hard reset. The AirPort will indicate if it's in hard reset mode by blinking faster.
Gulfport Airport's Gates: How Many Are There?
You may want to see also
Explore related products
$20.49
Factory reset instructions
There are two types of reset you can perform on your Apple Extreme Base Station: a Soft Reset and a Hard Reset. A Soft Reset is useful if you have forgotten your base station password and can no longer configure the Airport Extreme. A Hard Reset is useful if your AirPort Extreme has stopped responding or has serious accessibility issues.
Soft Reset instructions:
- Disconnect any Ethernet cables from the base station.
- Select System Preferences from the Apple menu in the top left-hand corner of the screen.
- Click on the Network icon to open Network Preferences.
- Select Airport from the list of connections on the left.
- Click on the Advanced button, then click on the TCP/IP tab.
- Set the Configure IPv4 to Using DHCP.
- Press and hold the reset button for 1 second.
- The middle LED will blink once every second while the device is in soft reset mode.
- The base station password will now be set to "public" and the IP address will be reset.
Hard Reset instructions:
- Disconnect the router from the power source.
- Locate the reset button.
- Using a straightened paper clip, pen, or similar, press and hold the reset button for 5-8 seconds while plugging the device back in.
- Wait until you see three status lights glow or the centre status light (LED) start to flash rapidly. The light should be an amber colour.
- Release the button and wait about a minute for the device to restart.
- Reconnect to your network and log in or register to add a comment.
Note: If you have a Graphite or Snow (Dual Ethernet) base station, connect your computer directly to the base station using an Ethernet cable.
Unveiling Cincinnati Airport's Fossil Mystery: A Unique Attraction
You may want to see also
Resetting the base station password
Firstly, you should determine whether a soft reset or a hard reset is more suitable for your needs. A soft reset is ideal if you have forgotten your base station password and can no longer configure the AirPort Extreme. On the other hand, a hard reset is recommended if your AirPort Extreme has stopped responding or has serious accessibility issues. In this case, the hard reset will revert your device to its default factory configuration.
If you choose to perform a soft reset, follow these steps:
- Ensure that your AirPort Extreme is connected to a power source.
- Disconnect any Ethernet cables from the base station.
- Access the Apple menu on the top left corner of your screen, then select System Preferences.
- Click on the Network icon to open the Network Preferences.
- Choose AirPort from the list of connections.
- Click on the Advanced button, then select the TCP/IP tab.
- Set the Configure IPv4 to Using DHCP.
Performing these steps will reset your base station password and disable security for approximately 5 minutes, allowing you to join the network and make any necessary changes. If no changes are made within this timeframe, your base station will automatically revert to its previous settings.
For a hard reset, there are a few different methods you can use, depending on your AirPort Extreme's firmware version.
If your AirPort Extreme has firmware 5.5.1 or later:
- Press and hold the reset button.
- Continue holding until the centre status light (LED) starts flashing rapidly, which should take about 5 seconds.
- Release the button, and your AirPort Extreme will reset.
For a factory-default reset, the following method is recommended for AirPort Time Capsule 802.11ac and AirPort Extreme 802.11ac with firmware version 7.9.1 or later:
- Disconnect the base station from its power source.
- Locate the reset button, usually found next to the ports.
- Press and hold the reset button while reconnecting the power plug.
- Hold the reset button for about 6 seconds, or until the status light flashes rapidly in an amber colour.
- Wait about a minute for the base station to finish restarting.
- You can now use AirPort Utility to reconfigure your base station, including setting a new password.
Another method for performing a hard reset, also known as the 30-30-30 reset, involves the following steps:
- When the router is powered on, press and hold the reset button for 30 seconds.
- While continuing to hold the reset button, unplug the power cord from the router.
- Keep holding the reset button for another 30 seconds.
- With the reset button still depressed, reconnect the power to the unit and hold for a final 30 seconds.
After performing any of these reset methods, you will be able to set a new password for your AirPort Extreme base station.
Bozeman Airport: Taxi Availability and Convenience
You may want to see also
Resetting the network password
Soft Reset
If you have forgotten your base station password and need to reset it, a soft reset is the recommended approach. This method will reset the base station password and temporarily disable security, allowing you to regain control of your Airport Extreme. Here are the steps to perform a soft reset:
- Ensure that your Airport Extreme is connected to a power source.
- Disconnect any Ethernet cables connected to the base station.
- On your computer, go to the Apple menu in the top left corner and select System Preferences.
- Click on the Network icon and then select the Airport option from the list of connections.
- Click on the Advanced button and navigate to the TCP/IP tab.
- Set the Configure IPv4 to Using DHCP.
- The soft reset is now complete. Your base station password will be reset, and you can now set up a new password.
Hard Reset
If your Airport Extreme is unresponsive or has serious accessibility issues, you may need to perform a hard reset. This method will revert your device to its default factory configuration. Here are the steps to perform a hard reset:
- Disconnect the power cable from the back of your Airport Extreme.
- Locate the reset button. It is usually a tiny button next to the power port.
- Use a pin, pen, or straightened paperclip to press and hold the reset button.
- While holding the reset button, reconnect the power plug to the Airport Extreme.
- Continue holding the reset button for about 5 to 8 seconds, or until you see the status light flashing rapidly in an amber color.
- Release the reset button and wait for about a minute for your Airport Extreme to restart.
- After restarting, your Airport Extreme will be reset to its factory settings, and you can set up a new network password.
30-30-30 Reset
Another method to reset your Airport Extreme A1301 is the 30-30-30 reset. This method involves a series of steps, each lasting 30 seconds. Here's how to do it:
- Power on your router and locate the reset button.
- Press and hold the reset button for 30 seconds. Use a paper clip or something sharp to press the button.
- While continuing to hold the reset button, unplug the power cord from the router and hold for another 30 seconds.
- Finally, while still holding the reset button, plug the power back into the router and hold for a final 30 seconds.
- Release the button, and your Airport Extreme will be reset to its factory settings.
Changing the Network Password
If you simply want to change your network password without performing a full reset, you can do so through the Airport Utility. Here's how:
- Open the Airport Utility application on your computer.
- Locate and select your base station from the list of available devices.
- Click on the Wireless tab in the Airport Utility.
- Edit the Wireless password field to enter a new password for your network.
- Optionally, you can turn on encryption (WPA2 is recommended) for added security.
- Click Update, and your new network password will be saved.
Please note that it is recommended to update your firmware to the latest version before performing any reset. Additionally, always refer to official Apple support for the most up-to-date and accurate instructions.
