Sectional charts are an essential tool for drone pilots, providing critical information about airspace hazards, topography, and airport data. They are also used to identify airports with control towers (blue symbols) and those without (magenta symbols). Airports with control towers operating only part-time will have a CTAF, and pilots should monitor both the airport's UNICOM and CTAF channels for communications. Symbols on sectional charts also indicate the type of airport, such as military airports with abbreviations like AAF, NAS, and NAV, and private airports with the letter R in a circle. Additionally, the charts provide insights into runway lengths, with specialists rounding lengths to the nearest hundred or thousand feet for representation on the charts.
| Characteristics | Values |
|---|---|
| How to identify an airport on a sectional chart | Airports can be found all over sectional charts and are some of the most important points of interest. |
| Symbols | Airports with control towers are blue, those without are magenta. |
| Military airports are represented by abbreviations like AAF, NAS, and NAV. | |
| A capital R enclosed by a circle denotes a private airport. | |
| Radio frequencies | Symbols representing airports can indicate which radio frequency to monitor for air traffic updates. |
| Runway information | A circular aerodrome symbol is used for runways between 7970 and 8069 feet in length. |
| If the runway is between 8070 and 8169 feet, specialists round it up to 8100 feet, which is too long for the largest circular aerodrome symbol. | |
| The length of the longest runway can be determined by the number in the symbol, expressed in hundreds of feet. | |
| Traffic patterns | "RP" in the airport information indicates a right traffic pattern, and the runway number will follow, e.g., "RP 32". |
| If "RP" is not noted, a left pattern is assumed. |
Explore related products
What You'll Learn
Airport symbols and their meanings
The Federal Aviation Administration (FAA), an operating mode of the US Department of Transportation, provides aeronautical charts and publications for each stage of Visual Flight Rules (VFR) and Instrument Flight Rules (IFR) air navigation. These include training, planning, departures, en route (for low and high altitudes), approaches, and arrivals.
The Sectional Aeronautical Charts are the primary navigational reference medium used by the VFR pilot community. The 1:500,000 scale Sectional Aeronautical Chart Series is designed for visual navigation of slow to medium-speed aircraft. The topographic information featured consists of the relief and a selection of visual checkpoints used for flight under VFR. The checkpoints include populated places, drainage patterns, roads, railroads, and other distinctive landmarks. The aeronautical information on Sectional Charts includes visual and radio aids to navigation, airports, controlled airspace, restricted areas, obstructions, and related data. These charts are updated every 56 days.
The FAA also provides a Notice to Air Missions Publication (NOTAM) that includes current Flight Data Center (FDC) NOTAMs. NOTAMs alert pilots of new regulatory requirements and reflect changes to Standard Instrument Approach Procedures (SIAPs), flight restrictions, and aeronautical chart revisions. This publication is prepared every 28 days by the FAA and is available by subscription from the Government Printing Office.
The FAA's Aeronautical Chart Users' Guide is updated when there is new chart symbology or when there are changes in the depiction of information and/or symbols on the charts. It is published in accordance with the 56-day AIRAC schedule. The guide is useful to new pilots as a learning aid and to experienced pilots as a quick reference.
Some examples of airport symbols and their meanings include:
- A circular aerodrome symbol is used for runways between 7970 and 8069 feet in length.
- If a runway is between 8070 and 8169 feet in length, specialists round to 8100 feet, which is too long to fit into the largest circular aerodrome symbol available.
- RP indicates that there are special conditions or restrictions for right-patterned traffic and the pilot should consult the Chart Supplement for those instructions and/or restrictions.
- The Parachute Jump Area symbol is used to indicate that an area meets the minimum charting requirements for parachute jumping.
