Airport diagrams, also known as airport charts or aerodrome charts, are maps that help pilots navigate taxiways and runways at a given airport. They are published by the Federal Aviation Administration (FAA) in the United States and are updated every 56 days unless there is a critical safety issue. Airport diagrams contain important information such as runway dimensions, slope angles, and hot spots—areas with a history or potential risk of collision. Aeronautical information changes frequently, so pilots must refer to the current editions of airport diagrams and discard outdated charts.
| Characteristics | Values |
|---|---|
| Purpose | Designed to assist pilots and ground traffic to navigate and move around complex runway and taxiway configurations |
| Publisher | Federal Aviation Administration (FAA) in the US; Terminal Procedures Publication; Jeppesen; Commercial providers |
| Frequency of Updates | Every 56 days unless there is a critical safety issue |
| Information Included | Coordinates, field elevations, runways, aprons, taxiways, hot spots, taxiway routes, air transit routes, lighting, air traffic control (ATC) service boundary, communication channels, obstacles, slope angles, buildings and service areas, VOR checkpoints, movement area permanently unsuitable for aircraft, runway length and width, upslope and downslope, weight-bearing capacity, FBO locations |
| Additional Information | Effective date; list of frequencies relevant to the airport; airport identifier, chart type, version number, version date |
Explore related products
What You'll Learn
- Airport diagrams are designed to assist ground traffic
- They help pilots navigate complex runways and taxiways
- They include information on runway length, width, slope, and magnetic heading
- Hot spots are marked on airport diagrams to indicate collision or runway incursion risks
- Airport diagrams include frequencies relevant to the airport
Airport diagrams are designed to assist ground traffic
Airport diagrams, also known as airport or aerodrome charts, are designed to assist ground traffic in navigating complex runway and taxiway configurations. They provide essential information to flight crews to facilitate the ground movement of aircraft between the aircraft stand and the runway. These diagrams are especially useful for pilots, enabling them to navigate taxiways and runways, even if they are visiting a particular airport for the first time.
The diagrams include details such as coordinates, field elevations, runways, aprons, taxiways, taxi routes, and lighting. They also indicate hot spots—areas with a history or potential risk of collision or runway incursion, requiring heightened attention from pilots and drivers. Additionally, airport diagrams may display information on chart relevance and accuracy, including airport identifiers, chart types, version numbers, and dates.
Pilots can use airport diagrams to determine which runway to use and the route to take when navigating an airport. This helps reduce task saturation and improves situational awareness for safer operations. For instance, a pilot starting from the West Ramp may refer to the diagram to anticipate using runway 3R and following a specific taxiway route to reach it.
Furthermore, airport diagrams show the location of the control tower, aiding pilots who are unable to establish radio communication with Air Traffic Control (ATC). They also provide runway information such as dimensions, slopes, touchdown zone elevation, and lighting systems. Pilots can also find important operational information, such as frequencies relevant to the airport, on the diagrams.
It is crucial to use current editions of airport diagrams as aeronautical information can change frequently. In the United States, these diagrams are published as part of Terminal Procedures Publication and are updated every 56 days unless there is a critical safety issue.
