Modifying a P3D airport can be a complex task, but with the right tools and knowledge, it is certainly achievable. P3D terrain is curved, so modelling a flat surface or importing a mesh will require applying a projection to match the terrain. This can be done using tools like ModelConverterX to adjust for the curvature of the Earth. Additionally, aerial imagery of the airport can be compiled into a .bgl file for reference in Prepar3D. When creating 3D objects, software like 3ds Max and Prepar3D SDK can be used, following steps such as assigning compatible materials, attaching unique identifiers, and exporting to specific file formats. Users can also adjust ground layouts using tools like Airport Design Editor (ADE) and substitute ground layouts with their own flat textured polygons.
Characteristics and Values of Modifying a P3D Airport
| Characteristics | Values |
|---|---|
| Terrain | Not flat, curved earth |
| Modelling | 3dsMax on a flat surface or imported mesh |
| Projection | Apply to the terrain to make it curved |
| Aerial imagery | Use for reference and compile to .bgl for use in Prepar3D |
| 3D objects | Create in 3ds Max |
| Ground layouts | Alter using Airport Design Editor |
| Scenery files | Can't usually change while Prepar3D.exe is running |
| Exclusions Rectangles | Longstanding bug from FSX |
| Runway | Set width using a ruler |
Explore related products
What You'll Learn
Modelling the airfield and runway
To model the airfield and runway, you can use the Airport Design Editor to alter ground layouts. This will help you visualise the layout of the runways, taxiways, and buildings, and how aircraft will move from parking spots to the runway. You can also use 3ds Max + Prepar3D SDK to create 3D objects.
When creating 3D objects, there are a few steps to follow:
- Create a model in 3ds Max
- Assign Prepar3D-compatible materials
- Attach a unique identifier (GUID) and a human-readable name
- Export to .X file
- Compile the .X file into an MDL model file
It's important to note that P3D Terrain is curved, so modelling in 3ds Max on a flat surface or with an imported mesh will not be accurate unless you apply a projection to the terrain to make it curved. You can use ModelConverterX to adjust your model to account for the curvature of the Earth. Additionally, find aerial imagery of your airport for reference and ensure that it is projected correctly in 3ds Max, especially for long, large objects like runways.
