The Apple AirPort Time Capsule can be used as a Network Attached Storage (NAS) device, but only as a sort of NAS. This is because the Time Capsule is a NAS server, which means it only delivers network storage space. To use the Time Capsule as a NAS, you need to connect it to an existing network and disable its wireless network functionality. This can be done by using the AirPort Utility to set the Time Capsule to Bridge Mode and disabling the wireless network in the Wireless tab. Once configured, the Time Capsule can be used as a NAS to store files on its internal and any external disks.
Explore related products
What You'll Learn
Time Capsule as a NAS device
The Apple Time Capsule can be used as a NAS (Network Attached Storage) device, but only as a "sort of" NAS, as one source puts it. This is because the Time Capsule is already running a minimal operating system, which makes the whole drive a network share.
To use the Time Capsule as a NAS, you will need to use the AirPort Utility to administer the Time Capsule. This is available for Mac, iOS, and Windows.
- Login to the Time Capsule using AirPort Utility.
- Click on the Time Capsule and select 'Edit'.
- Under 'Network', 'Router Mode', choose 'Off (Bridge Mode)'. This will allow your Time Capsule to join an existing network.
- Under 'Internet', select 'DHCP' so that when a network becomes available, it will choose a valid IP address automatically.
- Go to 'Wireless' and set the 'Network Mode' to 'Off'. This will disable the wireless network that the Time Capsule can create.
- Close the menu and let the Time Capsule reboot.
- Attach a LAN cable from your existing router to the WAN port on the Time Capsule.
Note that this setup will only work if you are connected via LAN. Additionally, it will only work on a Mac, not with a Windows or Linux system.
Once set up, you will be able to store files on the internal and any external disks of your Time Capsule.
How to Access Airport Lounges for Free
You may want to see also
Explore related products
Using AirPort Utility
To use your AirPort Time Capsule as a NAS, you will need to use the AirPort Utility. This is available for Mac, iOS, and Windows.
First, power up your Time Capsule but do not connect it to anything. This will allow it to create a WiFi network so you can connect to it from your system. Next, log in to the Time Capsule using AirPort Utility. Click on the Time Capsule and select 'Edit'. Under 'Network', choose 'Router Mode' and select 'Off (Bridge Mode)'. This will allow your Time Capsule to join an existing network.
Next, under 'Internet', select DHCP so that when a network becomes available, it will choose a valid IP automatically. You can also provide a static IP here. Go to Wireless and set the Network Mode to Off. This will disable the wireless network that the Time Capsule can create. Note that this will only work if you are connected via LAN.
Now you can attach a LAN cable from your existing router to the WAN port. Make sure it is CAT 5E at least so that your devices can connect at gigabit speed. If you are using a Mac and want to use the device as a Time Machine backup destination, open Time Machine and add it as a disk. It should show up as a shared drive, along with any attached USB drives. On a Mac, the Time Capsule is also accessible from the Finder under the 'Network' section. Double-click the device and log in with the credentials specified through AirPort Utility. Once logged in, you will be able to store files on the internal and any external disks.
Duty-Free Shopping: Manchester Airport Arrival Perks
You may want to see also
Explore related products
Selecting Bridge Mode
To select Bridge Mode when setting up your Time Capsule as a NAS, follow these steps:
First, connect your Time Capsule to a single Mac using an Ethernet cable. Plug the cable into one of the Time Capsule's LAN ports. On the Mac, turn off Wi-Fi to ensure a sole connection to the Time Capsule.
Next, launch the AirPort Utility on your Mac. You can download this from the Mac App Store if you don't already have it. Select your Time Capsule from the window and press 'Edit'.
Now, you need to configure two items:
- Disable the wireless functions of the Time Capsule: Select the Wireless tab and, under the Network Mode drop-down menu, select Off. This will disable any wireless networks created by your Time Capsule.
- Set your Time Capsule to Bridge Mode: Select the Network tab. Under the Router Mode drop-down menu, select Off (Bridge Mode).
Once you've made these changes, press 'Update'. Your Time Capsule will then reboot to enable the new configurations.
Finally, disconnect your Mac from the Time Capsule, re-enable your Wi-Fi if necessary, and connect your Mac to your primary Wi-Fi network.
Note: Some sources suggest that it may not be necessary to turn off the wireless function of the Time Capsule. If you encounter any issues, you can contact Apple Support for assistance.
Airport Security: Pants Pockets and Personal Items
You may want to see also
Explore related products
Time Machine backups
Apple's Time Capsule, introduced in 2008, is a combination of a wireless AirPort Base Station and an internal hard drive along with the macOS Time Machine backup software. Time Capsule acts as a Network Attached Storage (NAS) device and allows users to manually back up their data by using a Time Capsule as a NAS volume or by using the Time Machine app to automate backups.
Time Capsule is a great way to ensure that all your Macs are backed up all the time. While its backup features are Mac-specific, Time Capsule works as a network router with devices from other manufacturers as well. Time Machine is the Mac's built-in backup software and is included for free with the Mac. It works whenever the Mac is on and is designed to work as a local, primary backup of your Mac, meaning the data stays physically close to the computer and is intended to be the first line of defence in case of a computer issue.
Time Machine can back up to the built-in disk of an AirPort Time Capsule on your network. Simply select the Time Capsule as the backup disk when setting up Time Machine on your Mac. Time Machine can also back up to an external storage device connected to the USB port of an AirPort Extreme Base Station (802.11ac model) or AirPort Time Capsule on your network: If the storage device isn’t using Mac OS Extended (Journaled) format, connect it to your Mac and reformat it with Disk Utility. Connect the storage device to a USB port on your base station, then turn it on.
To use an Apple Time Capsule as a NAS without being a router, you can disable the wireless network that the Time Capsule can create. This will only work if you are connected via LAN. You can also use the AirPort Utility app on a Mac to prevent the Time Capsule from acting as a WiFi access point or router and use it only as a backup disk.
Find Almond and Rice Milk at O'Hare Airport
You may want to see also
Explore related products
![Yottamaster 1 Bay NAS Storage for 2.5" SATA HDD/SSD, Quad Core CPU, 1GbE Port, 1GB RAM DDR4, Network Attached Storage Device for Home & Personal Cloud Storage [Diskless]](https://m.media-amazon.com/images/I/71j8O0dM7QL._AC_UY218_.jpg)
Storing files on internal and external disks
The Apple AirPort Time Capsule can be used as a Network Attached Storage (NAS) device, allowing users to store files on both its internal and external disks. This can be achieved by following a series of steps to configure the Time Capsule.
Firstly, it is important to note that this setup is intended for use with Time Machine backups on a Mac and may not work with Windows or Linux systems. To begin, users need to launch the AirPort Utility and log in to the Time Capsule. Under the Network settings, Router Mode should be set to "Off (Bridge Mode)", allowing the Time Capsule to join an existing network. For Internet settings, DHCP should be selected to enable automatic IP assignment. Additionally, under Wireless settings, the Network Mode should be turned off to disable the wireless network created by the Time Capsule.
After configuring these basic settings, users can connect a LAN cable from their existing router to the WAN port on the Time Capsule. It is recommended to use a CAT 5E cable or higher to ensure gigabit-speed connectivity. With these connections in place, the Time Capsule can now function as a NAS device.
To store files on the internal and external disks of the Time Capsule, users can open Time Machine on their Mac and add it as a disk. This will make the Time Capsule appear as a shared drive, along with any attached USB drives. Users can then double-click on the Time Capsule drive and log in using their credentials set up through AirPort Utility. Once logged in, they will be able to store files on both the internal and external disks of the Time Capsule.
It is important to consider the potential performance implications of using the Time Capsule as a NAS. Since the Time Machine commonly writes to the same disk, accessing files stored on the internal disk may result in slower speeds and sporadic performance. Therefore, it is recommended to use a separate external drive connected to the Time Capsule if consistent and fast access to stored items is required.
Traveling with a Hydro Flask: Airport Security Rules
You may want to see also
Frequently asked questions
Yes, it is possible to use an Apple Airport Time Capsule as a NAS (Network Attached Storage) device without it being a router.
To use your Airport Time Capsule as a NAS, you will need to use the AirPort Utility. You will need to connect your Time Capsule to your existing network and set it to Bridge Mode. This will prevent it from creating its own network.
Using an Airport Time Capsule as a NAS allows you to store arbitrary data on the internal or USB-attached drive. It is also a cost-effective solution, as Time Capsules can be purchased for relatively low prices.
One drawback is that the setup process can be complicated, and it may not work with certain routers. Additionally, the WiFi on older Time Capsules may be slow.
Yes, it is possible to use a Time Capsule as both a NAS and a router. However, if you want to use it as a NAS without it acting as a WiFi access point or router, you will need to set it to Bridge Mode.
