Body Scanners Vs Metal Detectors: Airport Security Protocols Explained

Airport body scanners are designed to detect objects on or inside a person's body for security screening purposes, without physical contact or the removal of clothing. They are an essential part of the airport security system and use different types of technology to achieve this.

Metal detectors are one of the most common types of security devices used at airports. They use magnetic fields to identify metal objects. Metal detectors create a magnetic field by using a brief pulse of electrical current. If there is any metal on the person walking through the detector, the magnetic field will reflect back to the machine, and a beeping noise will sound to alert the security agent.

Another type of body scanner used at airports is the millimeter wave scanner. These machines use non-ionizing electromagnetic radiation to detect a wide range of metallic and non-metallic objects. Millimeter wave scanners are considered safer than other types of scanners as they do not generate ionizing radiation.

Backscatter X-ray scanners are another type of body scanner used at airports. These machines use low-energy X-rays to scan the body and detect objects hidden under clothing. Backscatter scanners have been phased out in many countries due to privacy and health concerns.

Overall, airport body scanners are an important tool for ensuring the safety of passengers and staff, but they have also raised concerns about radiation exposure and privacy.

Metal detectors use magnetic fields to identify metal objects

When considering airport security measures, it is important to understand the difference between body scanners and metal detectors. A simple online search reveals that indeed, metal detectors use magnetic fields to identify metal objects, whereas body scanners utilize advanced imaging technology, which will be further explained below.

Metal detectors function by generating a magnetic field and analyzing disturbances within that field. This is achieved through the use of a coil of wire that emits a specific frequency, typically between 5 and 10 kHz. When a metal object passes through the magnetic field, it disrupts the field's flux, causing a change in voltage or current in the coil. This change is then detected and signaled, indicating the presence of metal. The strength of the magnetic field and the sensitivity of the detector vary depending on the specific device and its intended use.

The principle behind this technology is based on Faraday's Law of Induction, which states that a changing magnetic field will induce an electromotive force (EMF) or voltage in a conductor. In the case of metal detection, the metal object acts as the conductor, and the changing magnetic field induces a current in the metal. This current creates a magnetic field that opposes the original field, resulting in a detectable change in the coil's voltage or current.

It is important to note that metal detectors are not limited to security checkpoints but have a wide range of applications. They are commonly used in industries such as food production and packaging to ensure product safety and quality control by detecting any metal contaminants. Additionally, metal detectors are employed in archaeology and treasure hunting to locate buried metal objects of historical value.

On the other hand, airport body scanners, often referred to as millimeter-wave scanners or advanced imaging technology (AIT), operate on a different principle. These scanners use safe electromagnetic waves to create an image of the body and any potential threats without making physical contact. The technology is designed to detect items made from a range of materials, including metal, plastic, and other non-metallic substances, providing a more comprehensive security screening.

In summary, metal detectors utilize magnetic fields to identify metal objects, whereas airport body scanners employ advanced imaging technology to detect a broader range of potential threats, ensuring the safety of passengers and staff. Both technologies play crucial roles in security and quality control measures across various industries.

Millimeter wave scanners use non-ionizing radiation to detect threats

Millimeter wave scanners emit a special type of microwave, not X-ray. They work by bouncing non-ionizing radiofrequency waves off the body and back to the machine. The waves go through clothing and reflect off the skin and any concealed items, creating an image that is interpreted by the machine. This image is a generic outline of a body, with any potential threats highlighted, to ensure privacy.

Millimeter wave scanners are important for airport security as they can detect hidden threats such as guns and knives, as well as metallic and non-metallic items. They are also useful for detecting objects for commercial loss prevention, smuggling, and screening at government buildings.

The use of millimeter wave scanners in airports has raised some concerns about privacy and health risks. To address privacy concerns, measures have been implemented, such as using generic body outlines and prohibiting the display of detailed images. In terms of health risks, millimeter wave scanners emit far less energy than a cell phone, and the risk of health effects is considered very low. However, there are still questions about the effectiveness of these scanners in detecting threatening objects, with some studies suggesting a high rate of false positives.

Backscatter X-ray scanners use low-dose radiation to detect objects under clothing

Backscatter X-ray scanners are a type of full-body imaging technology used to detect hidden objects on a person's body. They use low-dose ionizing radiation to scan for objects that may be hidden under clothing or in body cavities. This technology differs from traditional X-ray machines, which detect objects based on the variation in X-ray intensity transmitted through the target. In contrast, backscatter X-ray technology detects the radiation reflected from the target.

Backscatter X-ray scanners have been deployed in airports to detect hidden weapons, tools, liquids, narcotics, and other contraband items. They can detect both metallic and non-metallic objects, making them more effective than metal detectors in finding potential threats. The dosage of radiation received by passengers is typically between 0.05 and 0.1 μSv, which is considered a low dose.

While backscatter X-ray scanners have been praised for their effectiveness in detecting hidden objects, there have also been concerns about privacy and health risks. Some critics argue that the images produced by these scanners amount to virtual strip searches and violate basic human rights. Additionally, there is a debate about the safety of the technology, with some studies suggesting that the radiation exposure may pose a negligible cancer risk, especially for frequent flyers.

Due to these concerns, backscatter X-ray scanners have been banned in some countries, including the European Union, which banned their use in airports in 2012. In the United States, the Transportation Security Administration (TSA) removed the original backscatter X-ray machines from airports by May 2013 and replaced them with Advanced Imaging Technology (AIT) or millimeter-wave scanning devices, which are considered safer and less intrusive.

Today, while some large US airports still use newer versions of backscatter X-ray scanners, most airports have adopted AIT or millimeter-wave technology for security screening. Passengers also have the right to refuse full-body scans and opt for alternative screening methods, such as a pat-down, if they have concerns about privacy or health risks.

Transmission X-ray scanners use penetrating radiation to detect objects inside the body

Transmission X-ray scanners are a type of full-body scanner that uses penetrating radiation to detect objects inside the body. This technology has been used in airports and train stations in many countries since 2007, supplementing metal detectors. Transmission X-ray scanners use a higher dosage of radiation than backscatter X-ray scanners, which are typically used to detect objects hidden under clothing or on the body's surface. The radiation used by transmission X-ray scanners passes through the human body and is then captured by a detector or array of detectors. This allows for the detection of objects hidden not only under clothes but also inside the human body, such as in body cavities or the stomach.

The dosage of radiation received by individuals undergoing this screening process is typically not higher than 0.25 μSv, which is regulated by American radiation safety standards. This dosage is comparable to the radiation exposure from a typical medical diagnostic X-ray of an extremity, such as a hand or foot (1 μSv), or an intra-oral dental X-ray (5 μSv). It is important to note that radiation safety systems and procedures are in place to ensure that radiation doses remain as low as reasonably achievable.

Transmission X-ray scanners are particularly effective at detecting metallic and non-metallic objects, addressing a growing concern for airline safety after several bombing attempts in the 2000s. They can also detect swallowed items or objects hidden in body cavities, making them a valuable tool for security screening. The use of this technology has sparked debates about safety and privacy, with some countries banning their usage due to concerns over potential health risks.

Overall, transmission X-ray scanners are a type of full-body scanner that utilizes penetrating radiation to detect objects inside the human body, enhancing security screening capabilities at airports and other transportation hubs.

Infra-red thermal conductivity scanners use temperature differences to detect foreign objects

Infra-red thermal conductivity scanners, also known as thermal imagers, are a type of full-body scanner that can be used to detect foreign objects without physically removing clothes or making physical contact. Unlike metal detectors, these scanners can detect non-metal objects, which became a growing concern after several attempts to bomb airliners in the 2000s.

Thermal imagers use infrared technology to detect heat emissions from various objects. This process involves capturing infrared energy, which is invisible to the human eye, and converting it into a visible light display. All objects emit infrared energy as a function of their temperature, and this energy can be detected and translated into a visual image by a thermal imaging system.

In the context of airport security, thermal imagers can detect slight temperature differences on the surface of clothing to identify the presence of foreign objects. The technology relies on the ability of contraband hidden under clothing to heat or cool the surface of the clothing faster than the skin surface. Warm air is used to heat up the clothing, and the rate at which the clothing cools depends on what is beneath it. Items that cool the clothing faster or slower than the skin surface will be identified by a thermal image of the clothing.

Thermal imagers can also be used in industrial settings for preventive maintenance, building maintenance, and security applications. They can detect overheating components, insulation failures, and other potential problems that may not be visible to the naked eye. In building maintenance, for example, thermal imaging devices can detect heat losses due to poor insulation or air leaks, as well as water leaks within walls or beneath floors.

Infra-red thermal conductivity scanners are less commonly used compared to X-ray-based and millimeter-wave scanners. However, they provide a valuable alternative to metal detectors and other full-body scanners, particularly for detecting non-metallic objects.
